BAKON GES-3L brushless power screwdriver manufacturer

  • Place of Origin: Guangdong, China
  • Brand Name: BAKON
  • Model Number: FES-3L
  • Power Source: Electricity
  • Rated Voltage: 30V
  • Frequency: 50/60HZ
  • Max. Torque: 1.176Nm
  • Dimensions: 211*50mm
  • Weight: 350g
  • Product Name: Electric Screwdriver
  • Application: Screwing
  • Feature: Reverse Switch
  • Voltage: 30V
  • Torque Range: 0.029-1.176Nm
  • Speed: 1000rpm
Quantity:

BAKON GES-2L screwdriver

Technical parameter

Aircraft type

GES-3L
GES-5L
GES-12L

Input Voltage

30V

Torque range

Kgf.cm

0.3-3
0.5-5
2-12

Lbf.in

0.260-2.604
0.434-4.340
1.736-10.416

N.m

0.029-0.294
0.049-0.490
0.196-1.176

Torque accuracy

±3%

±3%

±3%

Torque adjustment

Stepless

Stepless

Stepless

Torque adjustment mode

Internal debugging
Internal debugging
Internal debugging

Start the way

Hand press type

Hand press type

Hand press type

Idling speed (R.P.M)

Slow series

200~1000
200~1000
200~1000

Weight (g)

350
350
350

No load current (A)

0.3A

0.3A

0.3A

Applicable starter

Φ4/5

Φ4/5

Φ4/5

Applicable screw

diameter(mm)

Mechanical tooth

1.0-2.3
1.0-2.6
2.0-3.0

Self-tacking tooth

1.0-2.0
1.0-2.3
2.0-2.5
Product features
  • Conical design, good line of sight, easy to disassemble and install.
  • The torque adjusts the patent design, the professional tool adjusts the torque, the torque setting is more
    accurate, the torque precision is higher. (domestic first technology patent).
  • The internal stop device adopts magnetic induction system, with high sensitivity, instantaneous braking, low
    impact force, and long-term use not easily damaged.
  • The gear assembly is made of high quality alloy steel, which is more durable and stable.
  • Low vibration, low noise, low electromagnetic interference, comply with environmental requirements, especially
    applicable to dustfree working environment.
  • The outer type is designed according to ergonomic grip, small volume, light weight, impact resistance,
    comfortable use, long time use not easy to fatigue, improve production efficiency.
  • The speed of 0-1000rpm can be adjusted to suit your different needs.
