Wrieless intelligent multifunction ground connection monitoring
Product specification
| Name | Wireless intelligent multifunction ground monitoring | ||
| Power | Input:DC9V/1A | ||
| Wrist strap(W)display range | Wrist power on | ≤2V | 750K-50MΩ Accuracy:<1M±0.15M;2-50M ±5% |
| Equipment (E)display range | ≤AC0.3V | 0.1-50Ω Accuracy:0-5R±0.3R;6-50Ω±5% | |
| Bench hook(M)display range | ≤2.5V | 1-100MΩ Accuracy:0.1-5M±0.5M;6-100M ±5% | |
| Voltage (AC)display range | ≤AC0.3V | 0-999mV Accyracy:1-10mV±1mV;11-999mV±5% | |
| Working environment | Anti-static workshop,-5-45℃ | ||
| Max consumption power | 3W | ||
| Indicator status | Normal-green;abnormal-red;standby-orange | ||
| Volume | 129*65*40 | ||
| Weight | 0.39kg | ||
Product feature
1. Choose the type of monitiring point that can monitor device at the same time,bench hoop,wrist strap,ground resistance,leakage voltage of equipment,the four kinds of modules can be combined with any three-way modules as required.
2. It can transmit the ground monitoring status to PC through wireless 2.4g for data collection and storage,which is convenient for query and analysis.
3. Adopt the principle of resistive monitoring,ensure the monitoring ibject is reliable grounding;
4. Compact and portable,flexible installation and expansion.
5. Suitable for modernize lean production management.
6. Light alarm and sound prompt function.
We have passed the GB/TI9001-2016/ISO9001-2015 international quality management system and our products have passed the CE certification,SGS certification,ATC certificatiom and so on.
In 1998, Shenzhen Bakon Electronic Technology Co., Ltd. was established at Shenzhen, and it is committed to the overall solution of static control, automation lean production, lead-free welding with its BAKON and SBK brand.Bakon insists on "technology-based, make the world brand", and pursues "soldering tools expert" in the world.
In 2012, Bakon becomes the supplier of GREE ELECTRIC, which is the biggest Air condition producer in the world. At the same time, we cooperate with BYD auto and many famous companies such as Foxconn, Apple's single-largest contractor, and so on.
In 2015, Bakon was identified as one Shenzhen High Technology Enterprise by Shenzhen Government.
Bakon now has more than 20 people of research and development team, including 6 electronic engineers, 2 software engineers and 6 automation engineers. Over the years, Bakon adhere consistently engaged to research of auto high power soldering station. In 2016, we launched model BK990 auto big power lead-free soldering station with measurement function of resistance and voltage.
The Smart ESD Control System, Network ESD Control System and Antistatic Online Control and Test System, which are Independent research and development products of Bakon, provide excellent solutions to ESD control of production lines, while there are more smart production lines and Carrying out of “Industry 4.0 strategy”. Specially, the Smart ESD Control System is applied to famous factories such as Gree Electric, BYD Auto, Hisense and so on.
Bakon's now No.2 in the domestic market and is known well in China, there is also more than 50% increasing in export amount each year. It’s sold to more and more countries, such as America, India, South Korea and so on.
Each of our products will be tested, the initial test passes, then aging, and finally test again.So if you find any traces of items used, please feel free to use, if you mind, we can talk about other options in detail.
Manufactory sell directly,the goods are in plenty supply,delivery date fast,good compete price.We have professional engineers who can meet your customized requirements.
Imported chip capacitors to form high-quality circuit boards.
We can ship within 7 days within 100pcs.More than 1000pcs need to be shipped within 45 days after payment.If you have other requirements, everything can be discussed.
Taking into account transportation issues, if there is a bad mail to us, you will spend a lot of transportation costs. So we will provide technical support and online communication.And we don't guarantee parts that are easy to wear, it is better to: soldering iron head, etc.Our warranty period is 1 year.
The last is the price, if you buy enough, we will give you a certain discount. For example, 50pcs, 100pcs unit price is different.
